DAVIES PUMPS CN SERIES FLANGE MOUNT END SUCTION PUMPS

The Davies Pumps CN series are rugged DIN standard cast iron single impeller pumps with flange mounts. They have been proven to be strong and reliable in closed loop chiller circuits, cooling towers, dairy sheds and many other wash-down applications.

Specifications:

Model No.	HP	kW	Inlet	Outlet	Pumping Height	Flow Rate
CN50-400	4.0	3.0	50mm	65mm	23m	950 lpm
CN50-550	5.5	4.0	50mm	65mm	25m	950 lpm
CN50-750	7.5	5.5	50mm	65mm	31m	1100 lpm
CN50-1000	10.0	7.5	50mm	65mm	40m	1200 lpm
CN50-1500	15.0	11.0	50mm	65mm	52m	1200 lpm

*Manufactured according to DN 24255 standards.
*Choose from the four ranges – 32, 40, 50 or 65 series.
*Max pumped liquid temp: 90°C.
*Max ambient temp: 40°C.
*Max working pressure: 10bar

Technical Features:

*Pump body: Cast iron G20 with anti-corrosive coating
*Motor bracket: Cast iron G20 with anti-corrosive coating
*Impeller: Cast iron G20 with anti-corrosive coating
*Orifices in/outlet: DIN 2532 standards
*Threaded counted flanges: Galvanised steel complete with EPDM gaskets.
*Pump shaft: Stainless steel Aisi 304
*Mechanical seal: Carbon ceramic
*Motor: Closed auto-ventilated motor with protection IP55, two poles, class F insulation.
*Three phase feeding with compulsory protection supplied by the user
*Continuous duty

Motor Features:

*Closed auto-ventilated motor with protection IP55, two poles,
*Class F insulation.
*Three-phase feeding with compulsory protection to be provided by the user.
*Continuous duty.
