GRUNDFOS UNILIFT CC Series

Please contact us regarding product as we don't always carry this item in stock

GRUNDFOS UNILIFT CC

The Grundfos UNILIFT CC is a submersible drainage pump ideal for all types of storm water and grey water handling around the home. Benefits include being able to pump down to just 3 mm of water - Can pump down to a water level of just 3 mm after removing the strainer, making it perfect for draining pools, ponds or tanks for maintenance.

Suitable for fully or partially submerged use, it comes with an integrated motor cooling jacket, allowing the pump to operate for extended periods whilst only partially submerged. High quality materials constructed of corrosion resistant composite and
stainless steel components inside and out. At a weight of no more than 7 kg, the UNILIFT CC can be used in either a permanent installation or as a portable drainage pump. Easy submerged installation – plug & pump - Connect the pump outlet to the pipework, plug into a power outlet and you’re ready to pump.

Specifications:

Model	Wattage	Head	Flow Rate
UNILIFT CC5	0.25	5m	100LPM
UNILIFT CC7	0.38	7m	166LPM
UNILIFT CC9	0.78	9m	250LPM

Technical Specifications:

* Outlet (Top)- ¾“, 1” or 1 ¼” Male
* Outlet (Side)- 1 ¼ “ Female
* Voltage: 230v/50Hz
* Single Phase
* Cable: 5m length with 3a plug
* IP68
* Semi Open Impeller

Operating Conditions:

* Max Particle Size: 10mm
* Max Installation Depth: 10m
* Minimum Pumping Level: down to 3mm (after removal of strainer)
* Liquid Temperature: 0°C to +40°C
* pH liquid value: 4-9

Application:

* Clean water drainage
* Storm/Grey water
* Tank, Pond & Pool drainage

Dimensions:
Height: 42cm
Width: 20cm
Depth: 20cm
Weight: 5.27kg

2 Year Back to Base Warranty
