Areta DCX Submersible Pump Series

240‑DCX500A

The DCX series are a cast iron high pressure submersible pump most commonly used to pump treated effluent to dripper lines. Featuring a large single impeller with high passage clearance up to 5mm to avoid blockages, double mechanical seal for long term durability and rugged cast iron construction. Available in three models with float switch to suit a wide range of applications.

Specifications:

Models	HP	kW	Amps	Pumping Height	Flow Rate
240-DCX500A	0.5	0.37	3.7	23m head	110 LPM
240-DCX1000A	1.0	0.75	5.3	27m head	130 LPM
240-DCX1500A	1.5	1.1	7.1	34m head	150 LPM



* Single Phase
* 230v
* Outlet- 1" (25mm)

Features:

* Cast iron pump housing and motor top cover
* 304 Stainless steel motor housing
* Glass fiber reinforced impeller
* Double-sided mechanical seal in oil bath
* Silicon carbide/silicon carbide – Pump side
* Carbon/Silicon carbide – Motor side
* Maximum liquid temperature: 40°c – continuous rated
* Class B rated motor insulation
* Incorporated motor thermal protector
* 10m Lead length
* Complete with Float switch supplied as standard

Applications:

* Drip Lines
* Treated effluent
* Clean Water
* Water Transfer

1 Year Warranty
