GRUNDFOS CMBE Booster Series

Please contact us regarding product as we don't always carry this item in stock

GRUNDFOS CMBE X-XX

The Grundfos CME Booster is a compact, frequency controlled booster designed for a variety of domestic and light industrial applications. The CME Booster ensures great comfort by providing constant pressure regardless of variations in demand or inlet pressure.

A variable speed pump that can be adjusted accordingly to water demand, resulting in lower running costs. All wetted components are constructed from high quality stainless steel ensuring, the water quality is not affected by pump materials. The pump will provide constant pressure at the tap (up to pump capacity), regardless of variation in demand or inlet pressure.

Includes 2L pressure tank

Specifications:

Model	kW	HP	Pumping Height	Flow Rate	Inlet/Outlet	PSI
CMBE 1-44	0.55	0.7	48m	50 lpm	1"	70
CMBE 3-62	1.1	1.5	65m	90 lpm	1"	94
CMBE 5-62	1.5	2	68m	130 lpm	1¼”	96

*Voltage: 240 V, 50 Hz
*Sold with a 2L pressure tank
*Enclosure class: IP55
*Insulation class: F
*Sound pressure level: 55 dB
*System pressure Max:10 bar
*Liquid temperature 0 °C to 60 °C
*Ambient temperature Max. 55 °C
*Relative air humidity Max. 95 %

Features

*Robust design
 All wetted parts are made from high quality stainless steel to ensure the longest life possible.
*Energy saving
The frequency controller of the CME Booster matches the power consumption with the required water output, helping to conserve energy.
*Easy installation
The CME Booster is very easy to install. Once the booster has been connected to the pipework, it is simply a matter of putting the plug into a socket, and the system is operational.
*Quiet operation
The CME Booster operates quietly, at around 55 decibels, significantly quieter than most pumps currently available on the market.
*User-friendly interface
The user-friendly interface features LED indicators showing operational status and buttons for pressure adjustment.
*Protective features
 The CME Booster features dry run protection to automatically stop the pump if the water source runs out. The pump is also protected against any accidental overload by built-in  thermal protection. These protective features help to ensure the longest life possible

Applications:

*Mains boosting
*Household water supply
*Pressure boosting from above ground water tanks
*Light industrial use

2 Year Back to Base Warranty
