Grundfos JP Series Household Pumps

Please contact us regarding product as we don't always carry this item in stock

The Grundfos JP is a compact booster pump designed for domestic and garden use. The booster unit consists of a Grundfos JP self-priming, composite, single-stage jet-pump, with PM1 pressure manager. The pressure manager allows the pump to start and stop automatically according to demand and protects the pump from dry run.

Specifications:

Model	kW	HP	Pumping Height	Flow Rate	Inlet/Outlet
JP 3-42	0.44	0.6	41m Head	60 Lpm	25mm 1"
JP 4-47	0.60	0.8	43m Head	75 Lpm	25mm 1"
JP 4-54	0.75	1.0	50m Head	75 Lpm	25mm 1"
JP 5-48	1.490	1.9	50m Head	90 Lpm	25mm 1"

* Suction-lift up to 7 meters
* 240v
* 50 Hz

Features:

• Self-priming
• Sold with Grundfos PM1 Controller
• Robust design
• Lightweight and corrosion resistance
• Dry running protection and cycling alarm
• Liquid temperature 0 °C to 35 °C
• Ambient temperature Max. 40 °C
• Enclosure class-IP44
• Insulation class- F
• S/Steel Shaft


Applications:

• Domestic Household
• Water Transfer
• Rainwater Tank

2 Year Back to Base Warranty
