Pentax CB Series-Twin Impeller-Irrigation and Washdown Pumps
The Pentax CB Series are a Cast Iron Twin impeller centrifugal pump designed for high flow and pressure systems for irrigation, farming and water transfer.
Available in three models
Specifications:
| Model | HP | kW | Flow Rate | Phase | Volts | Amps | Max Head | Inlet | Outlet |
| CBT160 | 1.5 | 1.1 | 120LPM | Three | 400 | 4.1 | 53m | 32mm | 25mm |
| CBT310 | 3 | 2.2 | 150LPM | Three | 400 | 5.2 | 64m | 32mm | 25mm |
| CBT600 | 5.5 | 4.0 | 225LPM | Three | 400 | 9.8 | 80m | 40mm | 32mm |
* Max Pressure: 75-116 psi
* Liquid Temperature: Brass impeller: 0 - 90 °C
* Maximum Operating Pressure: 11 Bar
* Enclosure Class: IP44
* Insulation Class: F
Features:
* Motor Shaft-Stainless Steel
* Brass Impeller
* Ceramic-graphite Mechanical Seal
* Continuous duty
Applications:
* Water Supply
* Irrigation, Industrial and Agricultrural Applications
(Three-phase feeding with compulsory protection to be provided by the user)
2 Year Warranty
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Pentax CB Series-Twin Impeller-Irrigation and Washdown Pumps
The Pentax CB Series are a Cast Iron Twin impeller centrifugal pump designed for high flow and pressure systems for irrigation, farming and water transfer.
Available in three models
Specifications:
| Model | HP | kW | Flow Rate | Phase | Volts | Amps | Max Head | Inlet | Outlet |
| CBT160 | 1.5 | 1.1 | 120LPM | Three | 400 | 4.1 | 53m | 32mm | 25mm |
| CBT310 | 3 | 2.2 | 150LPM | Three | 400 | 5.2 | 64m | 32mm | 25mm |
| CBT600 | 5.5 | 4.0 | 225LPM | Three | 400 | 9.8 | 80m | 40mm | 32mm |
* Max Pressure: 75-116 psi
* Liquid Temperature: Brass impeller: 0 - 90 °C
* Maximum Operating Pressure: 11 Bar
* Enclosure Class: IP44
* Insulation Class: F
Features:
* Motor Shaft-Stainless Steel
* Brass Impeller
* Ceramic-graphite Mechanical Seal
* Continuous duty
Applications:
* Water Supply
* Irrigation, Industrial and Agricultrural Applications
(Three-phase feeding with compulsory protection to be provided by the user)
2 Year Warranty
