TREVOLI CVF20-5 - Stainless Steel Vertical Multistage Water Pump with Variable Speed Controller

CVF20-5VP

This pump is ideal for high volume medium head applications such as washdown.  Fitted with a variable speed constant pressure controller and 18L pressure tank.

Specifications:

* Power -5500W - 7.37 Horsepower
* Three phase
* Max Flow rate: At 500 litres per minute
* Max Pressure: 102 psi
* Max discharge head: 71 metres
* Max suction 1.5m
* Inlet size: 2inch BSP (50mm)
* Outlet size: 2 inch BSP (50mm)
* Built in thermal overload protection
* Insulation class F
* IP55 Protection
* Rated for Continuous duty
* Liquid temperature range: -20 - 104 deg C
* Max operating pressure: 16 bar
* Height: 969 mm
* Weight: 83 Kg (pump only)

Common Applications:

* Domestic water supply for large / very large homes
* Farm irrigation
* General water transfer systems
* Industrial/commercial applications

Features:

* Fitted with a variable speed constant pressure controller
* Delivery pressure can be easily adjusted at any time
* Controller provides soft starts to avoid water hammer and related problems
* Pump motor operates at varying speed based on actual demand saving up to 50% electricity usage
* Run Dry Protection
* Corrosion resistant stainless steel construction
* Stainless steel pump housing
* Stainless steel motor shaft
* Stainless steel impeller and intermediate chambers
* Build in thermal overload protection
* Quiet operation

2 Year back to base warranty



CVF Series Brochure
