GRUNDFOS SCALA1 Series

Please contact us regarding product as we don't always carry this item in stock

The GRUNDFOS SCALA1 is a robust all-in-one, self-priming pump with built-in Bluetooth® connectivity, making it simple to install, trouble shoot and customise using the GRUNDFOS GO App. SCALA1 is self-priming, allowing it to be connected to either above ground or below ground (up to 8m) water sources.

Specifications:

Model	Wattage	Pumping Height	Flow Rate	Inlet/Outlet
SCALA1 3-45	800w	45m Head	85 LPM	25mm/1"
SCALA1 5-55	1000w	55m Head	110 LPM	25mm/1"

Features:

• For water sources below pump level - Designed with good suction lift capabilities, the SCALA1 is able to draw water up to 8 metres vertically below the level of the pump
• Quiet operation - Super quiet operation that won’t disturb your family or neighbours
• All-in-one construction - Tough, weather resistant outer casing houses the pump, motor and the controller
• Easy installation – plug & pump - Simply connect the pump inlet and outlet to the pipework, prime the pump, plug into a power outlet and you’re ready to pump
• Simple to operate and monitor - Seamlessly connect to your SCALA1 using the Bluetooth connected Grundfos GO App.

Technical Features:

* Suction Lift: 8m
* 230Volt
* Single Phase
* 50 Hz
* System Pressure: Max 8 Bar
* dB: 55
* Ambient Temperature: 0°C to +55°C
* Liquid Temperature: 0°C to +45°C
* Power Cable: 1.5m with Plug
* Enclosure Class: IPX4D
* Auto start/Stop
* Dry Run Protection
* Anti-Cycling Protection
* Alarm Indication LED

Application:

*Household water supply
*Pressure boosting from above ground rainwater or holding tanks
*Pressure boosting from below ground water sources
*Mains boosting
*Irrigation

Dimensions:

Length: 466mm
Height: 263mm
Width: 202mm
Weight:
- 3-45: 12KG
- 5-55: 14KG

Additional Information:

Brochure
Instruction Manual
Technical Brochure

2 Year Back to Base Warranty
