Pentax CAB300 Series Single Phase- Cast Iron Self-Priming Centrifugal Pumps

The Pentax CAB Series are self-priming centrifugal pumps designed for water transfer and supply (even if mixed with gas). They are ideal household and civil systems, when connected to autoclave tanks, they become automatically pressurised. The CAB series are a twin impeller design & are an efficient pump capable of lifting water 8-9 meters from below.

Specifications:

* Power: 2.2kW/3HP
* Head: 62m
* Flow Rate: 140 LPM
* 230v/Single Phase
* Amps: 13a
* Inlet 40mm
* Outlet 25mm
* Insulation: Class F
* Protection: IP44
* Rating: Continuous
* 15 AMP Plug

Features:

* Suction Lift - 8 Metres
* Heavy Duty Build
* Cast Iron Body & Motor Bracket
* Ceramic Mechanical Seal
* Stainless Steel Shaft
* Built in thermal overload protection

Operation limitations:

*Liquid temperature range: 0ºc to +50ºc
*Maximum operating pressure: 8bar/116PSI

Applications:

* Irrigation
* Water transfer
* Wells, Ponds, Lakes, Rivers
* Household small-large
* Civil Systems

2 Year Warranty
