Pentax Ultra 9S Series - Stainless Steel Multistage Pumps

ULTRA 9S‑200/4, ULTRA 9S‑250/5

The Pentax Ultra S range are stainless steel multistage pumps well suited to house and farm water supply. They have a robust fully stainless steel wet end and are very quiet in operation. The Ultra S Series are available in a wide range of models to match your application. They can also cover a wide range of applications such as pumping of clean non-loaded fluids, irrigation, drinking and glycol water, water treatment, heating and air conditioning and washing systems.

Specifications:

Model	Flow (lpm)	Head (M)	KW	HP	Amps	Phase
Ultra 9S-200/4	240	48	1.5	2	8.4	Single
Ultra 9S‑250/5	240	60	1.85	2.5	10.8	Single

*Inlet 40mm
*Outlet 32mm

 Features:

* Liquid temperature: -5 - +35 °C
* Maximum operating pressure:  8.5 bar (125 PSI)
* Enclosure class: IP44
* Insulation class: F
* Duty rating: Continuous
* Totally enclosed, fan cooled standard squirrel frame type motor
* Single phase versions fitted with auto reset internal overload

Technical features:

* 304 Stainless steel impellers, Diffusers, Seal plate & Pump casing
* 303 Stainless steel pump shaft
* Mechanical Seal: ceramic-graphite (6 impellers or less)
* Mechanical Seal: graphite-silicon carbide (7 impellers or more)
* Aluminium motor bracket

Applications:

* House and farm water supply
* Clean Water/Rain Water/Tank Water
* Pressure boosting
* Water treatment
* Industrial circulation
* Hot water cleaning systems

2 Year Back to Base Warranty
