Grundfos Unilift AP Series
Please contact us regarding product as we don't always carry this item in stock
GRUNDFOS AP12.40.04.A1
The UNILIFT AP 12 is a single-stage, submersible pump with semi-open impeller, designed for pumping drainage water containing particles up to a size of up to 12 mm. UNILIFT AP12 is for automatic as well as manual operation and can be used in a permanent installation or as a portable pump. The pump is easily installed as itās fitted with a carry handle and 10 m mains cable. UNILIFT AP12 is mostly made of stainless steel, with a stainless steel sleeve for cooling during operation. The stainless steel pump sleeve is made in one piece with a clipped on suction strainer for easy removal in case of maintenance.
Specifcations:Ā
| Model | Voltage | Phase | Wattage | HP | Head | Flow Rate | Outlet |
| UNILIFT AP12.40.04.A1 | 240v | Single | 0.4 | 0.5Ā | 11m | 250 LPM | 1 1/2" (40mm) |
| UNILIFT AP12.40.04.A3 | 415v | Three | 0.4 | 0.5Ā Ā | 11m | 250 LPMĀ | 1 1/2" (40mm) |
| UNILIFT AP12.40.06.A1 | 240v | Single | 0.6 | 0.8Ā | 13mĀ Ā | 300 LPMĀ | 1 1/2" (40mm) |
| UNILIFT AP12.40.06.A3 | 415v | Three | 0.6 | 0.8Ā | 13mĀ | 300 LPMĀ | 1 1/2" (40mm) |
| UNILIFT AP12.40.08.A1 | 240v | Single | 0.8 | 1.0Ā | 14mĀ | 350 LPMĀ | 1 1/2" (40mm) |
| UNILIFT AP12.50.11.A1 | 240v | Single | 1.1 | 1.5Ā | 16mĀ Ā | 550 LPMĀ | 2" (50mm) |
Please Note:Ā
A1 models include float switch for automatic operation
A3 models include float switch (10m) and control box with contactor and overload
* 50Hz
* Cable- 10m
* Particle Size-12mm
* Liquid temperature 0 Ā°C to 55 Ā°C Max
* pH concentration: 4 to 10
* Max. installation depth: 10 m
(Please enquire about models with no float switches)Ā
Features:Ā
* Robust design:Ā The materials of the pump ensure excellent corrosion resistance.
* Pump housing and impeller are made of high quality stainless stee
* Mechanical shaft seal offers high-wear resistance and a long operating life.
* Thermal overload protection
* The single-phase version is effectively protected against any accidental overload by built-in thermal protection. This means that no additional motor protection is required.
* Handy and easily transportable
* The carry handle mounted on the pump housing makes it handy and easily transportable.
* Option for automatic operation- The pumps are available with float switches for automatic on/off operation.
* Enclosure class: IP68
* Insulation class: F
* Cable type H07RN-F
Application:Ā
* Dirty Water
* Waste Water
* Clean WaterĀ
* Grey Water
Dimensions:Ā
| Model | Height | Width | Weight |
| UNILIFT AP12.40.04 | 321 | 216 | 11 |
| UNILIFT AP12.40.06 | 321 | 216 | 11 |
| UNILIFT AP12.40.08 | 346 | 216 | 12.6 |
| UNILIFT AP12.50.11 | 357 | 241 | 15.1 |
2 Year Back to Base WarrantyĀ Ā
