ZENIT-DRBLUEP SERIES

Please contact us regarding product as we don't always carry this item in stock

DR BLUE Series - Dreno ‘Drainage’ - Open multi-vane fully submerged impeller. Suited for domestic and commercial applications including all de-watering tasks, pumping out sumps, swimming pools, flooded areas, sewerage/effluent pumping and drawing water from wells.

Specifications:

Model	Wattage	HP	Flow Rate	Max Head
DR50	370w	0.5 hp	250 lpm	9 metres
DR75	550w	0.75 hp	300 lpm	12 metres
DR100	750w	1.0 hp	350 lpm	14 metres
DR150	1100w	1.5 hp	500 lpm	15 metres
DR200	1500w	2.0 hp	690 lpm	17 metres

* Foreign body size:  5mm to 30mm
* 1 ¼" to 2"outlet
* Also available in 3 phase, Please enquire about no float switch options

Features:

* New series of submersible drainage pumps for domestic and professional use.
* DR (DRENO) version with multi-vane fully submerged impeller for efficient operation.
* Float switch standard on single-phase versions.
* 10 m power lead (with 3 pin plug on single-phase pumps). Suits outdoor installations.
* Patented sealing system incorporating dual silicon carbide / graphite alumina mechanical seals in oil bath. Longer seal life.
* Anti-stressing system for power cable. Reduces cable damage and water entry.
* Cable holder grommet built into handle. Allows adjustment of float switch cable length.
* Cast iron pump body. For durability.
* Suction screen. To keep out hard solids.
* Ergonomic plastic carry handle. For safety and comfort.
* Supplied with standard power cables
* 10 Metre electrical cord

Technical Features:

* Maximum operating temperature 40 °C
* Maximum immersion depth 20 m
* PH of treated fluid 6 to 14 pH
* Max starts per hour 30
* Nominal absorbed current (In) 4.1 A
* rated power factor (cos phi) 0.94
* Nominal power frequency (f) 50 Hz
* N° phases 1
* IPMotor 68

Materials:

* Case Grey Cast Iron - EN-GJL 250 (02)
* Shaft Stainless Steel - AISI 420 (23)
* Cooling jacket Not applicable (00)
* Standard gasket Rubber - NBR (77)
* EX gasket Not applicable (00)
* Nuts and bolts Stainless Steel - Class A2-70 (42)
* Hydraulic Grey Cast Iron - EN-GJL 250 (02)
* Impeller Plastic (73) Cutting disk Not applicable (00)
* Cutter Not applicable (00)
* Grid Plastic (73)

Applications:

* Effluent pump
* Drainage pump
* General water pump
* Sumps
* Swimming pools
* Sewage

Click here for brochure

Made in Italy and comes with a 2 Year Warranty
