TREVOLI - BCV-750A Cast Iron Vortex Submersible Dirty water / Sewage Pump 750w

TREVOLI BCV-750A - Cast Iron Submersible Dirty Water / Sewage Pump

Suitable for use as an Effluent Pump, Dirty Water Pump, Drainage Pump, Septic and Aerated sewage treatment Pump, Grey Water Pump and Irrigation Pump

Specifications:

*Power: 750 Watt (1 HP) (6.5amp)
*Flow rate: 500 L/min
*Max delivery height: 10 metres
*Max immersion depth: 8 metres
*Weight: 18.5 kg
*Outlet size: 50mm

Head (metres) / Flow (LPM)

3	510
4.5	430
6	330
7.5	200
9	70



Features:

*Easy to use
*Non clogging Vortex impellor design
*Rated for continuous use
*Can process long fibres and solids up to 50mm
*Has a float switch for run-dry protection
*Motor has built in auto-reset thermal overload protection
*Double mechanical seals with oil chamber and lip seal for added protection
*10 Metre R05RNF neoprene chemical and oil resistant electrical cable with 3 pin plug
*Comes with cast iron 50mm outlet hose fitting (removable)
*Solid Cast Iron pump body and impeller for durability

Limitations:

1. The maximum depth it is allowed in water is 8m from its centre of impeller
2. Liquid to be pumped should have a PH: 6-8
Common Applications: Effluent pump, Drainage pump, Dirty water pump.

BCV Series Brochure

24 month (2 Year) Warranty
